WorkshopData™ Electronics

From: 77,00 per month for 12 months

Including both Tech and Electronics pack, this module helps technicians identify, locate and resolve electrical system errors and component errors using intelligent data applications, such as our Vehicle Electronics Smart Assistant (VESA ™).


Online Demonstration & 24/7 Technical Support

  • Enjoy a free 10mn demonstration
  • Availability of a dedicated team
Guaranteed Safe Checkout

haynespro logicat


workshopdata Electronics

With electrical systems and advanced technologies taking an ever more prominent place in modern cars, WorkshopData Electronics has become an essential application for technicians. At its heart lies HaynesPro’s unrivalled Vehicle Electronics Smart Assistant (VESA™).

Identification data


Identifying a vehicle is the critical first step in finding relevant pieces of information. WorkshopData Tech features extensive search methods* such as VRM, KBA, engine code, VIN and type which help you select the correct vehicle. A three-step graphics-based vehicle selection is also available.

VESA (Guided Diagnostics)

VESA™ is an innovative electronics diagnostics application. It retrieves data from the vehicle’s CAN-Bus system to help technicians diagnose faults and component errors which have generated fault codes. Up to seven fault codes can be entered simultaneously. VESA™ then presents the technician with descriptions of the fault codes, together with a suggested list of components to test.

  • Wiring diagrams for engine management, ABS, ESP and air conditioning
  • Component locations and information
  • Fault codes (manufacturer and EOBD)
  • Diagnostics wizard
  • Ground point locations
  • Links fault codes to the Smart Module


Clearly ‘located’ wiring diagrams for all key vehicle functions, with wiring and component tracking functionality for quick and efficient initial repairs. Also contains pan and zoom functionality, which is an advanced highlight feature to locate cables and corresponding components.


Comfort wiring diagramsWiring diagrams covering e.g. door locks, power windows, airbags, exterior lighting, start / load and wash / sweep systems Pan and zoom functionality Highlight function to locate cables and related components
haynespro wiring diagrams

Fuses and Relays

Always useful, HaynesPro has created an electronic module with essential information, characterized by this function of clear fuse location and identification. Fuse boxes can be installed in different places on a vehicle, making it more difficult to find them. The fuse locations are also accessible directly from the wiring diagram.

Cars | Trucks | Motorcycles

Fuses and relaysFuse and Relay Box LocationsOverview of fuses and relays

Additional information

Vehicle type

Cars, Trucks

Number of users

2 Users, 4 Users


7 days free trial ( No credit card required ), Annual payment, Monthly payment (Minimum 12 months commitment)
